WebElement Commands in C#

So far in our Selenium Learning journey, we have done WebDriver Commands and Navigation Commands. Soon we will be identifying the different WebElement on webpages and performing various actions on it. This chapter is all about Selenium WebDriver WebElement Commands. But before moving on to finding different WebElements, it better to cover that what all operations we can perform on a WebElement. In this chapter, we will learn What is WebElement and the List of Actions can be performed on various WebElements.

What is WebElement?

WebElement represents an HTML element. HTML documents are made up by HTML elements. HTML elements are written with a start tag, with an end tag, with the content in between: <tagname> content </tagname>

The HTML element is everything from the start tag to the end tag: <p> My first HTML paragraph. </p>

HTML elements can be nested (elements can contain elements). All HTML documents consist of nested HTML elements.

<html>
	<body>
		<h1> My First Heading </h1>
		<p> My first paragraph. </p>
	</body>
</html>

List of WebElement Commands/Actions

All interesting operations to do with interacting with a page will be performed through this IWebElement Interface.

Element_Commands_1

Before going through each and every action of IWebElement, let's just understand that how we get an IWebElement object/element. As in the previous chapters, we learned that every method of the IWebDriver either returns something or return void(means return nothing). The same way FindElement command of IWebDriver returns IWebElement.

Element_Commands_2

So, to get the IWebElement object write the below statement:

IWebElement element = driver.FindElement(By.Id("UserName"));

And now if you type element dot, Eclipse's intellisence will populate the complete list of actions just like the above image.

One more thing to notice that IWebElement can be of any type, like it can be a Text, Link, Radio Button, Drop Down, WebTable or any HTML element. But all the actions will always populate against the any element irrespective of whether the action is valid on the IWebElement or not. For e.g. Clear() command, even if you have a link element still you get the option to choose Clear() command on it, which if you choose may result in some error or may not does anything.

Clear Command

void IWebElement.Clear() - If this element is a text entry element, this will clear the value. This method accepts nothing as a parameter and returns nothing.

Command - element.Clear();

This method has no effect on other elements. Text entry elements are INPUT and TEXTAREA elements.

IWebElement element = driver.findElement(By.Id("UserName"));
element.Clear();

//Or can be written as

driver.FindElement(By.Id("UserName")).Clear();

SendKeys Command

void IWebElement.SendKeys(string text) - This simulate typing into an element, which may set its value. This method accepts string as a parameter and returns nothing.

Command - element.SendKeys("text");

This method works fine with text entry elements like INPUT and TEXTAREA elements.

IWebElement element = driver.FindElement(By.Id("UserName"));
element.SendKeys("ToolsQA");

//Or can be written as

driver.FindElement(By.Id("UserName")).SendKeys("ToolsQA");

Click Command

void IWebElement.Click()- This simulates the clicking of any element. Accepts nothing as a parameter and returns nothing.

Command - element.Click();

Clicking is perhaps the most common way of interacting with web elements like text elements, links, radio boxes and many more.

IWebElement element = driver.FindElement(By.LinkText("ToolsQA"));
element.Click();

//Or can be written as

driver.FindElement(By.LinkText("ToolsQA")).Click();

Note: Most of the time we click on the links and it causes a new page to load, this method will attempt to wait until the page has loaded properly before handing over the execution to next statement. But If Click() causes a new page to be loaded via an event or is done by sending a native event for example through javascript, then the method will not wait for it to be loaded.

There are some preconditions for an element to be clicked. The element must be Visible and it must have a Height and Width greater than 0.

Displayed Command

bool IWebElement.Displayed{ get; } - This method determines if an element is currently being displayed or not. This accepts nothing as a parameter but returns boolean value(true/false).

Command - element.Displayed;

IWebElement element = driver.FindElement(By.Id("UserName"));
bool status = element.Displayed;

//Or can be written as

bool staus = driver.FindElement(By.Id("UserName")).Displayed;

Note: Do not confuse this method with elements present on the page or not. This will return true if the element is present on the page and throw a NoSuchElementFound exception if the element is not present on the page. This refers to the property of the element, sometimes the element is present on the page but the property of the element is set to hidden, in that case, this will return false, as the element is present in the DOM but not visible to us.

Enabled Command

bool IWebElement.Enabled{ get; } - This determines if the element currently is Enabled or not? This accepts nothing as a parameter but returns boolean value(true/false).

Command - element.Enabled;

This will generally return true for everything but I am sure you must have noticed many disabled input elements in the web pages.

IWebElement element = driver.FindElement(By.Id("UserName"));
bool status = element.Enabled;

//Or can be written as

bool staus = driver.FindElement(By.Id("UserName")).Enabled;

//Or can be used as
IWebElement element = driver.FindElement(By.Id("UserName"));
bool status = element.Enabled;

// Check that if the Text field is enabled, if yes enter value
if(status){
    element.SendKeys("ToolsQA");
}

Selected Command

bool IWebElement.Selected{ get; } - Determine whether or not this element is selected or not. This accepts nothing as a parameter but returns boolean value(true/false).

Command - element.Selected;

This operation only applies to input elements such as Checkboxes, Select Options and Radio Buttons. This returns True if the element is currently selected or checked, false otherwise.

IWebElement element = driver.FindElement(By.Id("Sex-Male"));
bool status = element.Selected;

//Or can be written as

bool staus = driver.FindElement(By.Id("Sex-Male")).Selected;

Note: In the later chapters of Check Box & Radio Buttons and Drop Down & Multiple Selects, we have covered many examples around it.

Submit Command

void IWebElement.Submit() - This method works well/better than the Click() if the current element is a form, or an element within a form. This accepts nothing as a parameter and returns nothing.

Command - element.Submit();

If this causes the current page to change, then this method will wait until the new page is loaded.

IWebElement element = driver.FindElement(By.Id("SubmitButton"));
element.Submit();

//Or can be written as

driver.FindElement(By.Id("SubmitButton")).Submit();

Text Command

string IWebElement.Text{ get; } - This method will fetch the visible (i.e. not hidden by CSS) innerText of the element. This accepts nothing as a parameter but returns a String value.

Command - element.Text;

This returns an innerText of the element, including sub-elements, without any leading or trailing whitespace.

IWebElement element = driver.FindElement(By.Xpath("anyLink"));
String linkText = element.Text;

TagName Command

string IWebElement.TagName{ get; } - This method gets the tag name of this element. This accepts nothing as a parameter and returns a String value.

Command - element.TagName();

This does not return the value of the name attribute but return the tag for e.g. "input" for the element <input name="foo"/>.

IWebElement element = driver.FindElement(By.Id("SubmitButton"));
String tagName = element.TagName;

//Or can be written as

String tagName = driver.FindElement(By.Id("SubmitButton")).TagName;

GetCssValue Command

string IWebElement.GetCssValue(string propertyName) - This method Fetch CSS property value of the given element. This accepts string as a parameter which is property name.

Command - element.GetCssValue();

Color values should be returned as rgba strings, so, for example if the "background-color" property is set as "green" in the HTML source, the returned value will be "rgba(0, 255, 0, 1)".

GetAttribute Command

string IWebElement.GetAttribute(string attributeName) - This method gets the value of the given attribute of the element. This accepts the String as a parameter and returns a String value.

Command - element.GetAttribute();

Attributes are Ids, Name, Class extra and using this method you can get the value of the attributes of any given element.

IWebElement element = driver.FindElement(By.Id("SubmitButton"));
String attValue = element.GetAttribute("id"); //This will return "SubmitButton"

Size Command

System.Drawing.Size IWebElement.Size{ get; } - This method fetch the width and height of the rendered element. This accepts nothing as a parameter but returns the Dimension object.

Command - element.Size();

This returns the size of the element on the page.

IWebElement element = driver.FindElement(By.Id("SubmitButton"));
Dimension dimensions = element.Size();
Console.WriteLine(“Height :” + dimensions.Height + ”Width : "+ dimensions.Width);

Location Command

System.Drawing.Location IWebElement.Location{ get; } - This method locate the location of the element on the page. This accepts nothing as a parameter but returns the Point object.

Command - element.Location();

This returns the Point object, from which we can get X and Y coordinates of specific element.

IWebElement element = driver.FindElement(By.Id("SubmitButton"));
Point point = element.Location;
Console.WriteLine("X cordinate : " + point.X + "Y cordinate: " + point.Y);
